+1-800-426-6301Standard Features
- 50 ft (15.2 m) input power cable (plug not included)
- 25 ft (7.6 m) 2 in (5 cm) supply hose
- 30 ft (9.1 m) #4 cabin sense line
- 30 ft (9.1 m) #4 door seal line
- 3 phase, heavy duty 40 hp motor
- Heavy duty start with solid state overload protection
- High output belt driven blower
- High efficiency industrial blower silencers
- Murphy MPC20 Digital Controller/Display
- Electronic potentiometer controlled flow
- 35-350 scfm (26.3 lbs/min) flow capacity with 2% accuracy reading
- 0-13.5 psig at aircraft capability with .25% accuracy pressure reading
- Certified door seal pressure gauge 0-60 psi (0-4 bar)
- Quiet 77.6 dBA at 3 ft (1 m)
- Heat exchanger for controlled air delivery temperature, 100-140º F (38-60º C)
- Air inlet filter
- Maximum cabin pressure and rate of climb settable warnings
- Hard rubber casters
- Finish: Durable Powder Coat Tronair Blue
Variants
- 15A7610-6000 - 208V/60HZ/3PH
- 15B7610-6000 - 230V/60HZ/3PH
- 15C7610-6000 - 380V/60HZ/3PH
- Currently Viewing 15D7610-6000 - 460V/60HZ/3PH
- 15E7610-6000 - 575V/60HZ/3PH
- 15F7610-6000 - 380V/415V/440V/50HZ/3PH
- 15G7610-6000 - 200V/220V/50HZ/3PH

TRONAIR
15D7610-6000
Specifications
Aircraft Applications
Resources
Specifications
Electrical
- Electrical V/Hz/Ph: 460/60/3
Performance
- Flow Range Scfm: 35-350
- Rate Of Climb Indicator Ft/Min (Cm/Sec): 0-6,000 (0-3,048)
Dimensions
- Height In (Cm): 71 (180)
- Length In (Cm): 83.5 (212)
- Weight Lb (Kg): 2,000 (907)
- Width In (Cm): 75.5 (192)
Aircraft Applications
Resources
-
Current Operation and Service Manual
Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
