Showing 1 - 11 of 11
-
Electric Towbarless Tug (30,000 lb capacity)- 2 year Tronair Platinum warranty
- Double hydraulic lift cylinders for raising and lowering nose wheel cradle
- Rugged 6 horsepower, 48V, continuous duty-cycle drive motor with digital logic controller
- Two speed transaxle power transmission
- Built in 12-24-28/30V power supply to assist starting aircraft engines
- Eight (eJP-3) and 16 (eJP-3L) deep cycle 6V batteries (Full recharge in 8 hours)
- On board battery charger (eJP-3), Stand alone battery charger (eJP-3L - charger ordered separately)
- Two speed manual winch
- Operator platform accommodates operator and a passenger
- Regenerative Braking through Motor Control
- Heavy gauge welded steel frame
- Two forward and rear facing headlights and amber strobe light
- Rubberized coating on aluminum diamond top plate
- Battery watering system
Aircraft Applications: -
Hydraulic Power Units, Diesel Engine Driven, 67 Series (CE)- 0-34 gpm, 250-4000 psi, flow and pressure ratings
- 24 volt, dual battery for cold weather starts
- 70 gallon stainless steel hydraulic reservoir with desiccant breather, drain valve, and air removal system
- Bright LED lighting on engine and hydraulic instrument panels, and unit corner lights for night operation
- Bypass Valve for loading and unloading
- Calibration Port Shut Off Valve
- CE Marked
- Convenient hangers and trays to hold and contain the hydraulic hoses when not in use on the aircraft
- Corrosion resistant galvanized sheet metal and resistant stainless steel hardware
- Cummins, QSB4.5P130, Tier 3, 130 HP, 1800 rpm diesel engine (Jet-A or diesel fuel)
- Dual system with 50' (15 m) pressure and return hoses, pressure and return coupling for both systems
- Easy access, light weight, removable pin hinged panels for full access to all maintenance components
- Engine block and grid heater for cold weather system
- Engine System Monitor: Back lit digital display and diagnosis (DDD) with hour meter, and LED indicator lights
- Finish: Durable Powder Coat Tronair Blue
- Hand Pump Gauge
- Hydraulic fluid sample port for contamination testing
- Hydraulic System Meters: Digital (0.1% FS) flow meter, digital (0.25% FS) pressure gauge, digital (0.5% FS) temperature gauge
- Hydraulic system open or closed loop
- Large 35 gallon fuel tank for 12+ hours of use
- Large forced air cooler (20+ HP heat removal) hydraulic heat exchanger, thermostat controlled cooling system
- Powder coated (and Jet-Glo) Skydrol and UV resistant painted steel panels
- Pressure Control Valve
- Pressure Filtration: 2 micron, non-bypass type (beta rating >200 @ 2 micron)
- Pressure Gauge Calibration Port
- Quiet Operation: Less than 85 dbA at three feet noise level
- Reservoir Service/Component Testing: Manual two stage hand pump (high volume / 5000 psi) with 2 micron, non-bypass type (beta rating >200 @ 2 micron) pressure filter
- Return Filtration: 5 micron, bypass type (beta rating > 300 @ 5 micron)
- Ruggedized frame with enclosed fork lift tubes and 10,000 lb tie down rings
- Running gear rated for 8500 lbs. and 10 mph, Four wheel Ackerman steering with leaf spring trailer towing system with two wheel parking brake
- Selector Valve to select between aircraft or HPU reservoir
- The Engine DDD is a multifunction tool, which displays many engine-operating parameters including oil pressure, oil temperature, running hours, RPM, coolant temperature and fuel consumption. For the technician, the DDD can display service reminders for filter replacements, active fault codes and stored service codes for easy engine maintenance and diagnostics
- User friendly engine control panel for easy operation, includes service tool socket
- Safety Features:
- Hydraulic high and low reservoir shutoff feature with LED warning and indicating lights (panel and stack)
- Hydraulic high temperature shutoff feature (160º F) with LED warning and indicating lights (panel and stack)
- Engine no fuel and low fuel, high temperature, and low oil pressure LED indicating lights (panel and stack)
- Lubricity and fuel/water separator with water-in-fuel (WIF) sensor
- Low coolant shut down system
- Pressure filter clogging indicator LED light with reset button
- Pressure gauge calibration port for (on unit) calibration with safety shut-off valve
- Emergency stop button, system pressure relief valve, maintenance only access panels, return system pressure relief valve, automatic warning and shutdown systems
- Fire extinguisher
-
Hydraulic Power Unit, 54 Series (CE)- Adjustable working pressure
- 3 phase, electric motor available in 10 voltages (50 or 60 Hz)
- Adjustable pressure compensated, variable voltage, piston pump
- 30 gal (114 l) stainless steel reservoir with desiccant air filtration
- Large oil cooler with 3 phase electric fan (16,000 btu/hr cooling capacity)
- High efficiency, non-bypassing pressure filter with 2-micron absolute, Microglass III element (Beta rating > 1,000 based on ISO 4572)
- Large capacity return filter with 5 micron absolute, Microglass III element (Beta rating > 200 based on ISO 4572)
- Easy access fluid sampling valve (meets ANSI T2.24.1-1991)
- 1-15 gpm (4-56 lpm) dual scale flow meter
- 52 Series - Standard 15 ft (4.57 m) pressure and return hoses
- Standard 50 ft (15.24 m) input power cord without input plug
- Finish: Durable Powder Coat Tronair Blue
- Length: 54 in (137 cm)
- Width: 51 in (130 cm)
- Height: 50 in (127 cm)
- HPU Quick Select Chart (P
Aircraft Applications: -
Portable Cabin Pressure Test Unit- Continuous duty air supply REQUIRED for operation of unit:
- 15-7609-6000-FJ - 110 SCFM at 100 psi (6.9 bar) minimum (150 psi) max
- 1 1/2 in (4 cm) 20 ft. (6.1 m) detachable cabin supply hose with quick disconnect
- 1 in (2.5 cm) ID minimum inlet hose required
- Replaceable air inlet filter element
- 30 ft (9.1 m) cabin sensor feedback hose
- 30 ft (9.1 m) door seal supply hose
- Pressure relief valve set at 13.25 to 13.75 psi (.91 to .95 bar)
- Cabin pressure 0 to 15 psi (0 to 0.97 bar) certified gauges
- System pressure 0 to 30 psi (0 to 2.07 bar) certified gauges
- Door seal pressure 0 to 60 psi (0 to 4 bar) certified gauge
- Certified flow meter
- 150 psi (10.3 bar) maximum shop air supply pressure
- 0 to 6,000 ft/minute (0 to 1,829 m/minute) rate of climb indicator
- ATA transport case with wheels and a retractable handle
- CE marked
- 15-7609-6000-FJ - Ambient temperature gauge 50 to 300º F (10 to 149º C)
- 15-7609-6000-FJ - Incoming air pressure gauge 0 to 200 psi (0 to 13.8 bar)
- 15-7609-6000-FJ - Incoming air shut off valve
-
Vendor:TRONAIRTier 4, 28.5 Diesel GPU (28.5 vdc, 600 continuous, 2,000 amp peak) (CE)
11-2820-0000
Tier 4, 28.5 Diesel GPU (28.5 vdc, 600 continuous, 2,000 amp peak) (CE)- Powered by the award winning Doosan Tier 4f electronic engine with full-authority electronic controls for more precise control over the performance of the engine
- Extended service intervals using extended service filters and lubricants, up to 500 hours between scheduled service
- Engine operates with Ultra-low Sulphur Diesel fuel
- Fuel/water separator with water-in-fuel sensor and electronic indication
- Large 35 gallon, high density cross-linked polyethylene fuel tank for 26 + hours of use
- Low fuel warning and no fuel shutdown system
- Shut down on low oil pressure and high engine temperature commonly seen listed as (LOP/HET protection)
- 12 volt control and starting circuitry for easy cold weather starting
- Automated glow plug control for cold weather starting
- Large engine Digital Display and Diagnostics module (DDD), this is a multi-function tool to view engine parameters and fault codes
- Automatic 60 second power off delay engine shutdown for turbo protection
- 3 year engine warranty
- Powerful 38kw, six phase alternator, rectifier and ripple filter for ultra low DC output ripple
- Maintenance free, long life single bearing
- Automatic voltage build-up and protection
- Adjustable peak output current limiting control, 2,000 amp peak, 600 amp continuous output
- Cable head voltage sensing and output voltage drop compensation system ensures full power is provided to aircraft
- Aircraft cable head interlock circuit
- Wiring and color code in accordance with CE, NFPA and NEC
- 30 ft (9.1 m) DC output cable
- Durable, compact, maneuverable, trailer mounted unit with fifth wheel steering
- Front wheel scrub brake for simplicity
- Weather resistant powder coated sheet metal to prevent corrosion
- Corner lights and stack light
- Large cable trays for easy cable stowage
- Finish: Durable Powder Coat Tronair Blue
- Standard Cold Weather Features:
- 120 V Block Heater
- Larger capacity starting battery 900 CCA AGM type battery
- Automatic Glow Plugs
- Insulation package for the engine enclosure and sound dampening
-
Multi-Head Storage Rack, Double- Mobile, strong and durable
- Stores 500 and 800 Series multiheads
- Swivel casters with 2 lockable wheels
- Stainless steel construction and hardware
- Low profile to fit under most aircraft wings
- Keeps hangar floor space organized
- Easy assembly
- Attach additional racks together as needed
- Finish: Low reflective stainless steel
-
Looking For Custom Parts?
Contact Us -
Multi-Head Storage Rack- Mobile, strong and durable
- Stores 500 and 800 Series multiheads
- Swivel casters with 2 lockable wheels
- Stainless steel construction and hardware
- Low profile to fit under most aircraft wings
- Keeps hangar floor space organized
- Easy assembly
- Attach additional racks together as needed
- Finish: Low reflective stainless steel
-
Towbar, Multi-Head (CE)- Attachment heads easily change and securely attach to towbar in seconds
- Multi-head system saves space and capital investment
- Heavy-duty welded aluminum construction
- Standard 2 3/16 in (5.6 cm) I.D. towing eye
- (To substitute a 2 7/8 in (7.3 cm) I.D. eyebolt insert the letter "A" as the third digit of the model number, e.g. 01A1202-0000)
- (To substitute a 3 in (7.62 cm) I.D. eyebolt insert the letter "B" as the third digit of the model number, e.g. 01B1202-0000)
- Positive locking pin secures attachment heads to towbar
- Both towbar and attachments adhere to aircraft factory towing specifications
- Accommodates over 60 different aircraft attachment towing heads
- Shock absorber protects nose gear during towing operation
- Pneumatic wheels to absorb towing speed shock
- Handles positioned in front and rear to lift towbar into position
- Finish: Durable Powder Coat Tronair Blue
Aircraft Applications: -
-
-
Electric Towbarless Tug (30,000 lb capacity) long- 2 year Tronair Platinum warranty
- Double hydraulic lift cylinders for raising and lowering nose wheel cradle
- Rugged 6 horsepower, 48V, continuous duty-cycle drive motor with digital logic controller
- Two speed transaxle power transmission
- Built in 12-24-28/30V power supply to assist starting aircraft engines
- Eight (eJP-3) and 16 (eJP-3L) deep cycle 6V batteries (Full recharge in 8 hours)
- On board battery charger (eJP-3), Stand alone battery charger (eJP-3L - charger ordered separately)
- Two speed manual winch
- Operator platform accommodates operator and a passenger
- Regenerative Braking through Motor Control
- Heavy gauge welded steel frame
- Two forward and rear facing headlights and amber strobe light
- Rubberized coating on aluminum diamond top plate
- Battery watering system
Aircraft Applications:
