Showing 1 - 12 of 17
-
-
-
-
-
-
Electric Aircraft Tug (115,000 lb capacity)- Backed by the Eagle 3 Year/3,000 Hour Warranty, the ETT-8X is equipped to pull up to 115,000 lbs. Ideal for towing Small to Midsize Business Jets, Military Aircraft, and Rotorcraft in all weather conditions.
- Four Wheel Drive
- Four Wheel Steer
- 135" Turning Radius
- Engineered and Tested to SAE/ IATA and International Design Standards
- All LED Lighting
- Visibility to Hitches - Front & Rear Sight Tunnels
- Inching Mode
- Emergency Stop Button in Front and Rear Adjacent to Hitch Area
- Side & Rear Mirrors
- Seat Belts
- USB & 12V Outlets
- Tablet/Document Holder
-
Looking For Custom Parts?
Contact Us -
-
Electric Aircraft Tug (173,000 lb capacity)
- Backed by the Eagle 3 Year/3,000 Hour Warranty, the ETT-12X pulls up to 171,000 lbs.Designed to move business jets such as the G650 and Global Express and regional jets such as the CRJ-900 and ERJ-175 in all weather conditions.
- Four Wheel Drive
- Four Wheel Steer
- 135" Turning Radius
- Engineered and Tested to SAE/ IATA and International Design Standards
- All LED Lighting
- Visibility to Hitches - Front & Rear Sight Tunnels
- Inching Mode
- Emergency Stop Button in Front and Rear Adjacent to Hitch Area
- Side & Rear Mirrors
- Seat Belts
- USB & 12V Outlets
- Tablet/Document Holder
-
Hydraulic Power Unit, 54 Series (CE)- Adjustable working pressure
- 3 phase, electric motor available in 10 voltages (50 or 60 Hz)
- Adjustable pressure compensated, variable voltage, piston pump
- 30 gal (114 l) stainless steel reservoir with desiccant air filtration
- Large oil cooler with 3 phase electric fan (16,000 btu/hr cooling capacity)
- High efficiency, non-bypassing pressure filter with 2-micron absolute, Microglass III element (Beta rating > 1,000 based on ISO 4572)
- Large capacity return filter with 5 micron absolute, Microglass III element (Beta rating > 200 based on ISO 4572)
- Easy access fluid sampling valve (meets ANSI T2.24.1-1991)
- 1-15 gpm (4-56 lpm) dual scale flow meter
- 52 Series - Standard 15 ft (4.57 m) pressure and return hoses
- Standard 50 ft (15.24 m) input power cord without input plug
- Finish: Durable Powder Coat Tronair Blue
- Length: 54 in (137 cm)
- Width: 51 in (130 cm)
- Height: 50 in (127 cm)
- HPU Quick Select Chart (P
Aircraft Applications: -
400 Hz AC, 90kVA, 28.5 VDC Diesel GPU (CE)- Powered by the award winning Doosan Tier 4f electronic engine with full-authority electronic controls for more precise control over the performance of the engine
- Extended service intervals using extended filters and lubricants, up to 500 hours between scheduled service
- Engine operates with Ultra-low Sulphur Diesel fuel
- Fuel/water separator with water-in-fuel sensor and electronic indication
- Large 35 gallon, high density cross-linked polyethylene fuel tank for 8+ hours of use
- Low fuel warning and no fuel shutdown system
- Shut down on low oil pressure and high engine temperature commonly seen listed as (LOP/HET protection)
- 12 volt control and starting circuitry for easy cold weather starting
- Automated glow plug control for cold weather starting
- Large engine Digital Display and Diagnostics module (DDD), this is a multi-function tool to view engine parameters and fault codes
- Automatic 60 second power off delay engine shutdown for turbo protection
- 3 year engine warranty
- Powerful 80kw, AVR and 90kVA alternator with SCR regulation
- Maintenance free, long life single bearing
- Automatic output build-up and protection
- Cable head sensing and output drop compensation system ensures full power is provided to aircraft
- Aircraft cable head interlock circuit
- Wiring and color code in accordance with CE, NFPA and NEC
- 30 ft (9.1 m) AC output cable
- Durable, compact, maneuverable, trailer mounted unit with fifth wheel steering
- Front wheel scrub brake for simplicity
- Weather resistant powder coated sheet metal to prevent corrosion
- Corner lights and stack light
- Large cable trays for easy cable stowage
- Finish: Durable Powder Coat Tronair Blue
- CE marked
- Unit allows simultaneous use of 400 Hz AC and 28.5 VDC
- Powerful 80kw, AVR and 90kVA alternator with SCR regulation and ripple filter for ultra low DC output ripple
- Adjustable peak output current limiting control, 2,000 amp peak, 600 amp continuous output
- 30 ft (9 cm) DC output cable
- Standard Cold Weather Features:
- 120 V Block Heater
- Larger capacity starting battery 900 CCA AGM type battery
- Automatic Glow Plugs
- Insulation package for the engine enclosure and sound dampening
-
400 Hz AC, 90kVA Diesel GPU (CE)- Powered by the award winning Doosan Tier 4f electronic engine with full-authority electronic controls for more precise control over the performance of the engine
- Extended service intervals using extended filters and lubricants, up to 500 hours between scheduled service
- Engine operates with Ultra-low Sulphur Diesel fuel
- Fuel/water separator with water-in-fuel sensor and electronic indication
- Large 35 gallon, high density cross-linked polyethylene fuel tank for 8+ hours of use
- Low fuel warning and no fuel shutdown system
- Shut down on low oil pressure and high engine temperature commonly seen listed as (LOP/HET protection)
- 12 volt control and starting circuitry for easy cold weather starting
- Automated glow plug control for cold weather starting
- Large engine Digital Display and Diagnostics module (DDD), this is a multi-function tool to view engine parameters and fault codes
- Automatic 60 second power off delay engine shutdown for turbo protection
- 3 year engine warranty
- Powerful 80kw, AVR and 90kVA alternator with SCR regulation
- Maintenance free, long life single bearing
- Automatic output build-up and protection
- Cable head sensing and output drop compensation system ensures full power is provided to aircraft
- Aircraft cable head interlock circuit
- Wiring and color code in accordance with CE, NFPA and NEC
- 30 ft (9.1 m) AC output cable
- Durable, compact, maneuverable, trailer mounted unit with fifth wheel steering
- Front wheel scrub brake for simplicity
- Weather resistant powder coated sheet metal to prevent corrosion
- Corner lights and stack light
- Large cable trays for easy cable stowage
- Finish: Durable Powder Coat Tronair Blue
- CE marked
- Standard Cold Weather Features:
- 120 V Block Heater
- Larger capacity starting battery 900 CCA AGM type battery
- Automatic Glow Plugs
- Insulation package for the engine enclosure and sound dampening
-
Engine Compressor Washer Cart (CE)- Stainless steel fluid tanks with large fill ports, bleed-off valve and safety pop-off valve
- Operates off 125 psi (8.6 bar) shop air
- Pressure regulator with certified pressure gauge provided for flow control
- Solution agitation circuit
- 2 - ASME certified steel compressed air storage tanks with drain valves (1 on 08-4048-0013, 0 on 08-4059-0013)
- Sturdy welded steel frame
- 20 ft (6 m) output hose
- Foot brake
- Finish: Durable Powder Coat Tronair Blue
- 4 ft (1.2 m) wand assembly with shut-off valve and 4 spray nozzles: 1.5, 3, 6, and 10 gpm (6, 11, 23, and 38 lpm)
Aircraft Applications:
