Showing 1 - 12 of 313
-
-
Standard Features
- Anodized aluminum housing
- #6 SAE female ports
- EPR or Vitron seals
- 2 micron absolute rating per ISO 4572
- Beta rating > 1000 at 4 micron
- Dirt capacity of 1.38 grams at < 50 psig
- 150 psi (10 bar) collapse rating
- 3,000 psi (207 bar) maximum pressure rating
- Length: 4.75 in (12 cm)
- Diameter: 1.5 in (3.8 cm)
- Dry Weight: 1 lb (.5 kg)
Aircraft Applications: -
Standard Features
- Anodized aluminum housing
- #6 SAE female ports
- EPR or Vitron seals
- 2 micron absolute rating per ISO 4572
- Beta rating > 1000 at 4 micron
- Dirt capacity of 1.38 grams at < 50 psig
- 150 psi (10 bar) collapse rating
- 3,000 psi (207 bar) maximum pressure rating
- Length: 4.75 in (12 cm)
- Diameter: 1.5 in (3.8 cm)
- Dry Weight: 1 lb (.5 kg)
Aircraft Applications: -
Standard Features
- CE Marked
- Single-operator loading/unloading
- Holds 3 oxygen cylinders (up to 9" diameter, 56" tall, 150 lbs; CGA 540 with check valves, max 2900 psi)
- Holds 1 nitrogen cylinder (same size as oxygen; CGA 580 with check valve, max 3000 psi)
- Pneumatic tires/tapered wheel bearings
- Narrow width and low profile design
- Parking brake
- Hose compartment storage tray
- Instrument Panel
- Powder coated heavy duty steel construction
- Compact frame allows for a tight turning radius
- Remote Nitrogen Powered Booster
Aircraft Applications: -
-
-
Looking For Custom Parts?
Contact Us -
-
-
-
-
-
Aircraft Servicing Equipment: Enhancing Aircraft Maintenance and Operations
The Air Transport Association (ATA)100 is a common referencing standard for commercial aircraft documentation, critical to aircraft maintenance. ATA chapter 12 focuses on the operational standards and guidelines of aircraft servicing equipment required for use during standard maintenance and operations. This category encompasses a broad range of tools and machinery designed to meet the rigorous standards for safely and effectively performing maintenance tasks, ensuring aircraft are ready for operation. As such, ATA-12-compliant aircraft servicing equipment is pivotal in routine maintenance procedures, including fluid replacement, system servicing and general upkeep. All of which is essential for maintaining aircraft performance and safety. If you're looking for ATA-12 aircraft maintenance equipment, look no further than Tronair for the best in the industry.
Our servicing equipment is engineered with precision, incorporating advanced technology and strong, durable materials to ensure reliability in the most demanding aviation environments. Tronair's commitment to innovation and quality makes our servicing equipment an integral part of maintenance operations for commercial, business and military aircraft globally. From hydraulic and engine oil dispensing to waste and water management, you'll find the ATA-12-compliant aircraft servicing equipment you need right here. Browse the entire selection today.
The Role and Use of ATA-12 Aircraft Maintenance Equipment
Our selection of ATA-12 aircraft maintenance equipment is curated to address the wide range of diverse and specific tasks in the aviation industry. Each piece is designed to enhance operational efficiency and ensure the highest safety and performance standards. The following list provides a detailed overview of the different types of ATA-12 servicing equipment available in our inventory, highlighting their roles and applications in aircraft maintenance.
-
Multi-Purpose Carts: serve various functions for ground crews, from transporting tools and parts to specific servicing tasks (nitrogen, hydraulic fluid, engine oil) to streamlining operations.
- Skydrol Recovery Carts: Skydrol, a fire-resistant hydraulic fluid widely used in the aviation industry, requires specialized handling. Skydrol recovery carts are designed to safely collect, store and transport Skydrol fluid, preventing contamination and ensuring that hydraulic systems maintain their integrity.
- Hydraulic and Engine Oil Carts: are critical for the maintenance of aircraft hydraulic systems and engines.
- Lavatory Carts: are designed for the sanitary removal of waste and the replenishment of fresh water. They ensure lavatory systems are maintained to high standards of hygiene and functionality, contributing to passenger comfort and health.
- Nitrogen Carts: Nitrogen is used in various aircraft systems, including tire inflation and struts, due to its stable and inert properties. Nitrogen carts facilitate the safe and efficient delivery of nitrogen, enabling maintenance crews to accurately service and maintain these systems.
- Oxygen Carts: service oxygen systems, which enhance passenger comfort under certain flight conditions. They ensure that oxygen is handled safely and readily available on aircraft when necessary.
- Potable Water Carts: ensure the availability of clean water onboard for handwashing, cooking and drinking. They play a vital role in maintaining aircraft health and hygiene standards and provide a critical service in the overall passenger experience.
- Shimmy Damper Servicing Carts: enable precise shimmy damper servicing, ensuring that dampers function effectively to mitigate vibration during takeoff, landing and taxiing operations.
An Inside Look at the Tronair Facility
Frequently Asked Questions: Aircraft Servicing Equipment
If you have any questions or would like to learn more about our selection of aircraft servicing equipment, check out the answers to our most commonly asked questions below.
