Showing 1 - 12 of 27
-
28.5 RCT 60HZ SGL NO CBL (CE- Quiet operation, 52dB during normal operation, 60dB maximum
- 20 A, 115 VAC, duplex GFCI weatherproof recptacle with cover
- MIL-STD-704F, 18" NEC and CE compliant
- Low profile and compact design
- Sturdy all weather IP54 enclosure with cord hangers
- Long life LED indication lights that double as a diagnostic tool
- Emergency stop switch
- Large 9 in (23 cm) rubber ridgid and lockable swivel casters for easy maneuverability
- Finish: Durable Powder Coat Tronair yellow
- Input - Easy to change multi-volt transformer
- Input - Main power disconnect switch
- Input - 25 KVA transformer ensures full power during engine starts
- Input - Voltage Range 200-480V +/- 10%
- Input - Frequency 50 Hz / 60 Hz
- Output - Current Limit (adjustable) 100-2000 max amps DC maximum
- Output - Nominal Continuous Power 600 amps at 28.5 VDC
- Output - DC Voltage (adjustable) 16-35V
- Output - Nominal DC Voltage 28.5 VDC
- Output - Clean power, low voltage ripple <.2 VDC RMS
- Output - DC On/Off switch on control panel
- Output - Remote DC output On/Off engine start capable
- Output - Remote DC voltage sensing
- Output - Simple to use operator control panel
- Protection - Output over/under voltage
- Protection - Output over current
- Protection - Input phase loss detection, missing phase
- Protection - Input over/under voltage
- Protection - Input shunt-trop circuit breaker 100 amps
- Protection - Transformer over temperature
- Protection - SCR over temperature
- Protection - Energy saving variable speed thermal control cooling fan
-
-
-
-
-
-
Looking For Custom Parts?
Contact Us -
-
-
Vendor:TRONAIR28.0 Rugged Terrain Gas GPU (28 vdc, 150 continuous, 1,000 amp peak) (CE)
11-6644C1010-A1
28.0 Rugged Terrain Gas GPU (28 vdc, 150 continuous, 1,000 amp peak) (CE)- CE marked
- 150 amps continuous at 28 VDC, 1,000 amps peak
- 6 heavy duty, maintenance free, lead acid batteries
- Soft start for avionics protection
- 2 cylinder, air cooled Tier 4 Kohler engine
- Internal battery charger recharges in minutes
- 20 ft (6.1 m) 4/0 output cable with AN 2551 connector aircraft DC plug
- 11-6644C1010-A1: Developed for the US Army
- 11-6644C1010-A1: Rugged frame for transport across rough terrain
- 11-6644C1010-A1: Towing speeds up to 20 mph
- 13 gal (49 l) fuel tank
- 0 to 125º F (-18 to 52º C) maximum aircraft starting and electric service temperature range
- Illuminated instrument panel
- Hourmeter
- 0-300 ammeter
- 0-3,000 aircraft ammeter
- 0-50 volt DC voltmeter
- Aircraft power cable On/Off switch
- Electric starter switch
- Meets California Clean Air
- Oil-bathed fly weight type governor
- OHC 18 HP
- Finish: Durable Powder Coat Tronair Blue
-
GPU, Gas (28 vdc, 150 continuous, 1,000 amp peak) (CE)- CE marked
- 150 amps continuous at 28 VDC, 1,000 amps peak
- 6 heavy duty, maintenance free, lead acid batteries
- Soft start for avionics protection
- 2 cylinder, air cooled Tier 4 Kohler engine
- Internal battery charger recharges in minutes
- 20 ft (6.1 m) 4/0 output cable with AN 2551 connector aircraft DC plug
- 11-6644C1010: 13 in (33 cm) tubless pneumatic tires
- 13 gal (49 l) fuel tank
- 0 to 125º F (-18 to 52º C) maximum aircraft starting and electric service temperature range
- Illuminated instrument panel
- Hourmeter
- 0-300 ammeter
- 0-3,000 aircraft ammeter
- 0-50 volt DC voltmeter
- Aircraft power cable On/Off switch
- Electric starter switch
- Meets California Clean Air
- Oil-bathed fly weight type governor
- OHC 18 HP
- Finish: Durable Powder Coat Tronair Blue
-
Battery Charger/Analyzer (NiCad)- Fully automatic operation
- Solid state circuirty and state-of-the-art components
- Automatic battery temperature sensing
- Battery over temperature protection circuit
- Services from 1 to 50 cells simultaneously
- Capable of discharging two batteries (limited to 20 amps)
- Adjustable current flow from 0 - 50 amps
- Input voltages 208/230 AC 50 or 60 Hz
-
Battery Cart (24 vdc, 1,800 amp peak)- Delivers 1,000 amps starting power
- Rugged welded steel construction
- 24 VDC output
- 20 ft (6.1 m) DC output cable with AN2551 connector
- Soft start protects avionics from voltage spikes
- 10 in (25 cm) pneumatic tires
- Contains (6) heavy duty, maintenance free lead acid batteries, with 950 cold cranking amps each at 0º F (-18º C)
- Finish: Powder Coat Tronair Blue
ATA-24 Ground Support Equipment: Solutions to Maintain Aircraft Electrical Systems
Aircraft electrical power systems are essential for maintaining and servicing aircraft electrical systems while they are on the ground. The ATA-24 aircraft electrical power category of equipment includes tools and devices designed to provide power, support battery maintenance, test electrical systems, and ensure the overall operational readiness of an aircraft's electrical components. Compliance with ATA-24 specifications, which refer to the aircraft's electrical power system, is crucial for maintaining the safety and efficiency of these operations.
At Tronair, we offer an excellent selection of aircraft electrical power systems tailored to meet the stringent requirements of modern aircraft maintenance. Our product range includes ground power units (GPUs), battery carts and chargers, and solid-state rectifiers. Each product is engineered to deliver reliable performance, ensuring your aircraft's electrical systems are properly maintained and ready for operation. Our commitment to quality and innovation makes us a trusted partner in the aviation industry, supporting safe and efficient ground operations worldwide.
Check Out the Tronair ATA-24 Lineup
Want to know more about our aircraft electrical power systems? At Tronair, we offer high-quality solutions that adhere to ATA-24 standards, including ground power units (GPUs), solid-state rectifiers, battery carts, and chargers. Let's take a closer look at what this equipment can do.
Ground Power Units (GPUs)
Ground Power Units (GPUs) are critical aircraft electrical power components. They supply external power to aircraft while on the ground, ensuring their electrical systems remain operational without depleting their batteries. External power is crucial for running onboard systems, performing pre-flight checks, and performing maintenance tasks.
-
Pre-Flight Preparations: GPUs provide the power to run diagnostic checks and ensure all electrical systems function properly before a flight.
-
Maintenance Operations: During routine maintenance or repairs, GPUs power various aircraft systems, allowing technicians to work without relying on the aircraft's internal power.
-
Reducing Engine Use: Using a GPU prevents the aircraft's auxiliary power unit (APU) from running, saving fuel and reducing wear and tear on the aircraft's engines.
Battery Carts and Chargers
Battery carts and chargers are designed to maintain and service aircraft batteries, integral to an aircraft's electrical systems. These units ensure that batteries are always charged and ready for use, supporting regular operations and emergency power needs.
-
Battery Charging and Maintenance: Battery carts and chargers keep aircraft batteries in optimal condition, ensuring they are fully charged and operational when needed.
-
Routine Checks: Regular battery maintenance prevents unexpected power failures and ensures reliable performance.
-
Emergency Readiness: Properly maintained batteries are essential for emergency situations, providing backup power if primary systems fail.
Solid-State Rectifiers
Solid-state rectifiers are an integral part of aircraft electrical power systems. They are designed to convert AC (alternating current) to DC (direct current) power, which most aircraft systems require. Rectifiers ensure a stable and reliable power supply to the aircraft's electrical systems during ground operations.
-
Power Conversion: Solid-state rectifiers convert AC power from ground power sources into the DC power required by the aircraft. This conversion is crucial for operating various electrical systems on the aircraft.
-
Stable Power Supply: They provide a steady and regulated DC power output, essential for properly functioning sensitive electronic systems on the aircraft.
-
Maintenance and Testing: During maintenance and testing, solid-state rectifiers ensure that the aircraft's systems receive the correct type of power, allowing technicians to perform accurate diagnostics and repairs.
Learn More About Aircraft Electrical Power Systems
Frequently Asked Questions: Aircraft Electrical Power Systems
If you have questions about our aircraft electrical power systems, check out the answers to our most frequently asked questions below.
Enhance Your Aircraft Maintenance With Tronair Electrical Power System
