Portable Utility Crane

Performance

• Capacity Lb (Kg): Lifting Position 1: 750 (340) Lifting Position 2: 750 (340) Lifting Position 3: 250 (113))
• Number Of Outriggers/Casters: 4
• Ramp Mobility (Degrees): 12

Dimensions

• Hook Height In (Cm): Lifting Position 1: 162 (411.5) Lifting Position 2: 162 (411.5) Lifting Position 3: 162 (411.5)
• Horizontal Reach In (Cm): Lifting Position 1: 70 (101.6) Lifting Position 2: 74 (188) Lifting Position 3: 82 (208.3)
• Outrigger Extended Radius In (Cm): 72 (182.9)
• Weight Lb (Kg): 590 (268)

• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
