Towable Floor Crane

Dimensions

• Boom Height In (Cm): Position 1: 228 (579.12) Position 2: 216 (548.64) Position 3: 168 (426.72)
• Hook Height In (Cm): Position 1: 212 (538.48) Position 2: 201 (510.54) Position 3: 154 (391.16)
• Length In (Cm): 209 (530.86)
• Weight Lb (Kg): 1750 (793.8)
• Width In (Cm): Leg Extended: 125 (317.5)

Performance

• Capacity Lb (Kg): 2000 (907)

• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
