MALABAR

8793 Axle Jack Cart

879300

Model879300

Lifting and shoring (ata-7)

Does this product fit your model?

View Aircraft Applications
Available to Order
Request a Quote
View full details

Standard Features

  • Axle Jack Cart
  • Oil Pressure at 95 Ton Axle Jack Rated Capacity ........................ 6440 psig (453 kg/sq cm)
  • Safety Pop-off Valve (field adjustable) factory set at ..................... 100 tons (91 m. tons)
  • Reservoir Capacity ............................................................................. 5.5 gal (20.8 liters)
  • Hydraulic Fluid ..................................................................................... Conoco Super Hydraulic 32 or equal
  • Hydraulic Hose (2 each) .................................................................... 20 ft (6100 mm)
  • Pneumatic Hose (1 each) .................................................................. 50 ft (15,240 mm)
  • Cart Dimensions and Weight:
  • Length ................................................................................................... 90 in (2,286 mm)
  • Width ..................................................................................................... 40 in (1,016 mm)
  • Height (towbar stowed) ...................................................................... 58 in (1,473 mm)
  • Weight ................................................................................................... 2700 lbs (1220 kg)
  • 1.4.2 95 Ton Axle Jacks (2 Each)
  • Rated Capacity .................................................................................... 95 tons (86 m. tons)
  • Low Height ........................................................................................... 10 in (254 mm)
  • Hydraulic Lift......................................................................................... 10 in (254 mm)
  • Extension Screw ................................................................................. 4 in (102 mm)
  • Total Extended Height ........................................................................ 24.00 in (610 mm)
  • Proof Load ............................................................................................ 142.5 tons (129.5 m. tons)
  • Floor Loading at Rated Capacity ...................................................... 950 psi (66.8 kg/sq cm)
  • Approximate Axle Jack Net Weight (dry) ........................................ 265 lbs (120 kg)
  • A field adjustable safety pop-off valve is incorporated in the axle jack cart (located at the lower right behind the control panel) to prevent axle jack lifting loads in excess of 100 tons (91 m. tons).
  • A relief valve with manual try lever is incorporated in the air inlet to prevent over pressurization of the pneumatic system.
  • The extension screw has a positive stop to prevent it from being extended beyond its safe thread engagement.
  • A load gauge for monitoring the approximate load being raised.
  • The 95 ton axle jacks have safety locknuts (with a retainer to prevent removal from jack) to prevent lowering under load.
MALABAR

879300

Request a Quote

Specifications

Performance

  • Capacity Tons: 95

Dimensions

  • Closed Height In (Cm): 10 (25)
  • Extended Height In (Cm): 24 (61)
  • Height In (Cm): 58 (143)
  • Hydraulic Extension In (Cm) (Hydraulic Lift): 10 (25)
  • Length In (Cm): 90 (229)
  • Mechanical Extension In (Cm) (Extension Screw): 4 (10)
  • Weight Lb (Kg): 2700 (1220)
  • Width In (Cm): 40 (102)

Type/Other

  • Hand Pump/Air Pump: Hand Pump
