8429E Axle and Tripod Jack Test Fixture (150 Ton)
842900E
SKU:Model842900E
Available to Order
Standard Features
- Rugged steel load bars, pins and test head
- Integral lift bar for easy positioning on jack
- 150 ton capacity electronic load cell
- Hand-held measuring Instrument
- 50 foot long cable to connect measuring instrument to load cell
- Battery operated with four "AAA" size batteries
- Easy zero and span adjustments
- Measuring instrument includes shunt-cal feature to verify calibration
- Multiple 3/4 inch (19 mm) male and female spherical radius adapters and 1 1/4 (32 mm) female spherical radius adapter
- Storage and shipping container with mounting hardware to secure test fixture parts
- Axle jack test kit
MALABAR
842900E
Specifications
Resources
Specifications
Dimensions
- Height In (Cm): 24.25 (62.2)
- Length In (Cm): 37 (94)
- Weight Lb (Kg): 900 (409)
- Width In (Cm): 30.5 (77.5)
Type/Other
- Jack Application: Malabar Tripod Jack Models using Standard Test Bars: 703, 711, 712B, 713A, 714A, 714D, 717A, 718A, 718B, 725A, 731, 733, 736A, 737, 743, 746, 748A, 749, 749S, 759A, 760, 761, 763, 767A, 768A, 775, 775S, 785, 789, 792, 793, 795, 796, 7120A, 7120B, 7120C, 7120D, 7120E, 7225A, 8281A, 8487, 8487A, 8551, 8552, 8704, 8713, 8721, 8721A, 8721AEMB, 8722, 8722A, 8730, 8730A, 8730B, 8731, 8756, 8761, 8769, 8802, 8803, 8803A, 8810, 8810A, 8811, 8811A, 8811B, 8823, 8826, 8841, 8850, 8850EMB, 8857, 8924, 8934, 8935 Malabar Two Stage Tripod Jack Models using Optional Test Bar Kits: Test Bar Kit P/N 842950: 7210B, 7210R, 7210S, 7210-S1 Test Bar Kit P/N 842951: 7235A, 8760, 8864, 8902 Test Bar Kit P/N 842952: 8863 Test Bar Kit P/N 842953: 8865, 8882, 8918 Test Bar Kit P/N 842957: 7215, 7215A, 7215B, 8923
Performance
- Rated Capacity Tons: Tripod: 150 Axle: 100
Resources
-
Current Operation and Service Manual
Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
