MALABAR

Tail Support Stanchion

70500C-1

Model70500C-1

Lifting and shoring (ata-7)

Does this product fit your model?

View Aircraft Applications
Available to Order
Request a Quote
View full details

Standard Features

  • Hydraulic operated with integral hand pump head stock (includes over center lock & 2 inch ball receptacle)
  • 14 inch diameter with ball swivel & adjustable screw Unipod foot pad
  • Towbar with 3 inch lunette eye and automatic parking brake
  • Ram hand pump assembly with 3 position fulcrum for low/medium/high pressure
  • Load gauge
  • Skydrol resistant paint (safety yellow)
  • 3 year standard warranty
  • Shipment on domestic skid

Optional Features

  • Air pump
  • Foam filled tires
  • Customer specified paint color
  • Export crating

Variants

  • Currently Viewing 70500C-1 - NONE
  • 70500C-3 - FOAM FILLED TIRE
  • 70500C-4 - AIR PUMP, FOAM FILLED TIRE
MALABAR

70500C-1

Request a Quote

Specifications

Specifications

Dimensions

  • Base Radius: Tripod Leg: 64 (162.5)
  • Closed Height In (Cm): 210 (533.4)
  • Extended Height In (Cm): 280 (711.2)
  • Hydraulic Extension In (Cm) (Hydraulic Lift): 70 (177.8)
  • Hydraulic Reservoir Capacity (Gal): 8.75
  • Weight Lb (Kg): 2750 (1247)

Performance

  • Rated Capacity Tons: 15
