TRONAIR

FLUID SERVICE , TOLUENE

06-5077-6700

Model06-5077-6700

Servicing (ata-12)

Does this product fit your model?

View Aircraft Applications
Available to Order
Request a Quote
Icons/Caret-Right

Separate Adaptor may be required for some aircraft models. View Adaptor

View full details

Standard Features

  • ASME certified stainless steel reservoir
  • 06-5009-Series, 06-5077-6700: 2.5 gal (9.5 l)
  • 06-5010-Series: 6 gal (28 l)
  • 2 micron filtration (beta rating > 1000 @ 4µm per ISO 4572)
  • 100 psi (6.9 bar) certified pressure gauge
  • 85 psi (5.9 bar) maximum pressure
  • 125 psi (8.6 bar) safety pop off valve
  • 15 ft (4.6 m) #4 hose with 37º JIC female swivel connector, shut off valve and filler tube
  • 8 in (20 cm) semi-pneumatic tires - Model 06-5010 only
TRONAIR

06-5077-6700

Request a Quote

Specifications

Fluids

  • Fluid: Touline

Dimensions

  • Height In (Cm): 17 (43)
  • Length In (Cm): 10 (25)
  • Weight Lb (Kg): 15 (6.8)
  • Width In (Cm): 10 (25)
