TOWBAR, PORT. CHALLENGER

Dimensions

• Height In (Cm): 6 (15.2)
• Length In (Cm): Length From eyebolt centerline to aircraft attachment centerline With middle section .......................... 114.25 in (290.2 cm) Without middle section ..................... 65.75 in (167 cm)
• Weight Lb (Kg): Weight Eyebolt Section ....................... 25 lbs (11.3 kg) Weight Middle Section ......................... 23 lbs (10.4 kg) Weight Towing Head ........................... 18 lbs (8.2 kg)
• Width In (Cm): 37.25 (94.6)

Performance

• Maximum Aircraft Gross Weight Lbs (Metric Tons): 40,000 lbs (18.1 Metric tons)

• G-1446-30 — PIN, SHEAR (AS REQUIRED)
• K-1337 — KIT, REPL. BALL LOC PIN (AS REQUIRED)
• K-1882 — KIT, REPL BALL LOCK PIN (AS REQUIRED)

• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
