TOWBAR, GLOBAL EXPRESS

Dimensions

• Height In (Cm): 8.56 (21.7) From ground to aircraft attachment.
• Length In (Cm): 152.06 (386.2) From eyebolt centerline to aircraft attachment
• Tube In (Cm): 4.5 (11.43) diameter
• Weight Lb (Kg): 173 (78.5)
• Width In (Cm): 37.25 (94.6)

Build

• Material: Aluminum, Steel Head

Performance

• Maximum Aircraft Gross Weight Lbs (Metric Tons): 95,000 lbs (43.1 Metric ton)

• G-1453-22 — Shear Pin (AS REQUIRED)
• U-1027 — Wheel (AS REQUIRED)

• Usage Instructions, Towbar
• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
