TOWBAR, PORTABLE S-61,S-70

Dimensions

• Height In (Cm): 5.25 (13.3)
• Length In (Cm): 139 in (353.1 cm) From eyebolt centerline to aircraft attachment centerline when fully extended 59 in (149.9 cm) Overall collapsed (towbar only) 27.9 in (70.9 cm) Overall towbar head (separate from towbar)
• Width In (Cm): 16.9 (42.9)

Build

• Material: Aluminum, Steel Head

Performance

• Maximum Aircraft Gross Weight Lbs (Metric Tons): 25,000 lbs (11.34 Metric tons)

• G-1310-0845 — PIN, 1/2 X 4.5 BALL LOK-T (AS REQUIRED)
• K-1401 — KIT, REPL. BALL LOC PIN (AS REQUIRED)
• K-1548 — KIT, REPL. BOLT (SET) (AS REQUIRED)

• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
