TOWBAR, BELL 525

Dimensions

• Height In (Cm): 15.37 (39) diameter
• Length In (Cm): 145.437 (369.4) From eyebolt centerline to end of towbar
• Weight Lb (Kg): 206.5 (90)
• Width In (Cm): 28.01 (71.2)

Build

• Material: Steel

Performance

• Maximum Aircraft Gross Weight Lbs (Metric Tons): 19,300 lbs (8.8 Metric ton)

• G-1310-0840 — PIN, 1/2 X 4.0 BALL LOK-T (AS REQUIRED)
• R-2832 — PIN, SLIDING (AS REQUIRED)
• U-1169 — WHEEL, 6" SOLID (AS REQUIRED)

• Usage Instructions, Towbar
• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
