TBAR, S-61, S-70, APACHE (CE)

Dimensions

• Height In (Cm): 7.6875 (19.5) From ground to aircraft attachment
• Length In (Cm): 222.75 (578.5) From eyebolt centerline to aircraft attachment centerline when fully extended
• Weight Lb (Kg): 176 (79.5)
• Width In (Cm): 22.75 (57.8)

Build

• Material: Aluminum, Steel Head

Performance

• Maximum Aircraft Gross Weight Lbs (Metric Tons): 25,000 lbs (11.34 Metric tons)

• G-1310-0415 — PIN, 1/4 X 1.5 BALL LOK-T (AS REQUIRED)
• R-2041 — PIN, SLIDING (AS REQUIRED)
• U-1027 — Wheel (AS REQUIRED)

• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
