TOWBAR, CUSTOM S-76 LNT

Dimensions

• Height In (Cm): 13.81 (35.1)
• Length In (Cm): 102 15/16 in (261.5 cm) From eyebolt centerline to aircraft attachment centerline
• Weight Lb (Kg): 75.5 (34.7)
• Width In (Cm): 22.875 (58.1)

Performance

• Maximum Aircraft Gross Weight Lbs (Metric Tons): 11,700 lbs (5.3 metric tons)

• K-1110 — KIT, REPL. SHOCK SPRING (AS REQUIRED)
• K-1111 — KIT, REPL. SLEEVE (OUT/IN) (AS REQUIRED)
• K-1112 — KIT, REPL. WHEEL (SINGLE) (AS REQUIRED)
• K-1565 — KIT, REPL. SAFETY CATCH (AS REQUIRED)

• Usage Instructions, Towbar
• Current Operation and Service Manual
  Please Note, this is the latest version of the OSM. If you need an OSM specific to your model and serial number, please use our OSM Search Tool here.
