Vendor:TRONAIRTiltable Four Bottle Service Cart (booster, manifold & high pressure regulator) (CE)
20-4523-0000
Standard Features
- 4 hose manifold to connect bottles with CGA-540 fittings (see accessories)
- High pressure regulator (non venting) 15 to 2,500 psi (1 to 172 bar) certified gauge with 15 ft (4.6 m) #4 output hose with 37º JIC female swivel connector
- 30:1 volumetric displacement
- 20:1 maximum compression ratio
- Oxygen overpressure relief valve set at 2,700 psi (186 bar)
- Temperature range 0º to 200º F (-17.7º to 93.3º C)
- Operating instructions located on instrument panel
- In-line 15 micron nominal filter
- Sturdy welded steel construction
- Holds four, 9 in (23 cm) diameter oxygen bottles (bottles not included), maximum bottle pressure 2,250 psi (155 bar)
- 13 in (33 cm) diameter pneumatic tires
- Front wheels lock with towbar in upright position (OSHA Act 1970 Section 5(a) (1) - General Duty Clause - an employer has the general duty to provide a safe work environment free from known hazards. Potential movement of the cart on an uneven surface or incline is eliminated by the locking front wheels)
- Towbar with 23/16 in (5.6 cm) ID eyebolt
- Maximum towing speed 10 mph (16 km/hr)
- Hose storage compartment
- Reflectors to improve night visibility
- Low Profile
- CE marked
- Finish: Powder Coat Green
- Removable back stop adjusts to fit bottle lengths from 48 to 64 in (122 to 163 cm) to hold bottles securely in place - 20-4504-7000 & 20-4505-7000 ONLY
- 2,500 psi (172 bar) oxygen intensifier (booster)
- Intensifier (booster) automatically shuts down when the aircraft reaches set pressure
- Easy, one person loading and unloading of 9" diameter x 56" long cylinders, no muscle strains from picking up cylinders (OSHA Act 1970 Section 5(a)(1) - General Duty Clause and EU OSHA Directive 90/269/EEC - Manual Handling of Loads)
- Extremely easy rotation to horizontal in use position (OSHA Act 1970 Section 5(a)(1) - General Duty Clause and EU OSHA Directive 90/269/EEC - Manual Handling of Loads)
- Extra secure locking pivot point
Aircraft Applications: -
-
-
-
-
Looking For Custom Parts?
Contact Us -
Vendor:TRONAIRFour Bottle Oxygen Service Cart (booster, manifold & high pressure regulator) (CE)
20-4505-7000
Standard Features
- 4 hose manifold to connect bottles with CGA-540 fittings (see accessories)
- High pressure regulator (non venting) 15 to 2,500 psi (1 to 172 bar) certified gauge with 15 ft (4.6 m) #4 output hose with 37º JIC female swivel connector
- 30:1 volumetric displacement
- 20:1 maximum compression ratio
- Oxygen overpressure relief valve set at 2,700 psi (186 bar)
- Temperature range 0º to 200º F (-17.7º to 93.3º C)
- Operating instructions located on instrument panel
- In-line 15 micron nominal filter
- Sturdy welded steel construction
- Holds four, 9 in (23 cm) diameter oxygen bottles (bottles not included), maximum bottle pressure 2,250 psi (155 bar)
- 13 in (33 cm) diameter pneumatic tires
- Front wheels lock with towbar in upright position (OSHA Act 1970 Section 5(a) (1) - General Duty Clause - an employer has the general duty to provide a safe work environment free from known hazards. Potential movement of the cart on an uneven surface or incline is eliminated by the locking front wheels)
- Towbar with 23/16 in (5.6 cm) ID eyebolt
- Maximum towing speed 10 mph (16 km/hr)
- Hose storage compartment
- Reflectors to improve night visibility
- Low Profile
- CE marked
- Finish: Powder Coat Green
- Removable back stop adjusts to fit bottle lengths from 48 to 64 in (122 to 163 cm) to hold bottles securely in place - 20-4504-7000 & 20-4505-7000 ONLY
- 2,500 psi (172 bar) oxygen intensifier (booster)
- Intensifier (booster) automatically shuts down when the aircraft reaches set pressure
Aircraft Applications: -
Standard Features
- 4 hose manifold to connect bottles with CGA-540 fittings (see accessories)
- High pressure regulator (non venting) 15 to 2,500 psi (1 to 172 bar) certified gauge with 15 ft (4.6 m) #4 output hose with 37º JIC female swivel connector
- 30:1 volumetric displacement
- 20:1 maximum compression ratio
- Oxygen overpressure relief valve set at 2,700 psi (186 bar)
- Temperature range 0º to 200º F (-17.7º to 93.3º C)
- Operating instructions located on instrument panel
- In-line 15 micron nominal filter
- Sturdy welded steel construction
- Holds four, 9 in (23 cm) diameter oxygen bottles (bottles not included), maximum bottle pressure 2,250 psi (155 bar)
- 13 in (33 cm) diameter pneumatic tires
- Front wheels lock with towbar in upright position (OSHA Act 1970 Section 5(a) (1) - General Duty Clause - an employer has the general duty to provide a safe work environment free from known hazards. Potential movement of the cart on an uneven surface or incline is eliminated by the locking front wheels)
- Towbar with 23/16 in (5.6 cm) ID eyebolt
- Maximum towing speed 10 mph (16 km/hr)
- Hose storage compartment
- Reflectors to improve night visibility
- Low Profile
- CE marked
- Finish: Powder Coat Green
- Removable back stop adjusts to fit bottle lengths from 48 to 64 in (122 to 163 cm) to hold bottles securely in place - 20-4504-7000 & 20-4505-7000 ONLY
Aircraft Applications: -
-
-
-
Standard Features
- CE marked
- 2,200 psi (151.7 bar) maximum output pressure
- 30:1 volumetric displacement
- 20:1 maximum compression ratio
- Shop air required 80 cfm (37.8 lps) at 90 psi (6.2 bar)
- 0-5,000 psi (0-345 bar) certified supply gauge
- 0-3,000 psi (0-207 bar) certified aircraft pressure gauge
- 0-160 psi (0-11 bar) certified shop air regulator gauge
- Temperature range 0º to 200º F (17.7º to 93.3º C)
- 15 ft (4.6 m) #4 stainless steel braided hose with 37º JIC female swivel connector
- In-line 15 micron nominal filter
- Booster automatically shuts down when aircraft reaches set pressure
- Finish: Powder Coat Green
Aircraft Applications:
