Showing 49 - 60 of 121
-
Standard Features
- Manual hand pump with high, medium and low pressure operating positions
- Heavy duty swivel casters
- Rain hat (covers jack upper head)
- Hard chrome plated cylinder bore
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 3 year standard warranty
- Shipment on domestic skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psi)g)
- Tow handle for ease of towing
- Customer specified paint color
- Export crating
Aircraft Applications: -
-
Standard Features
- Manual hand pump with high, medium and low pressure operating positions
- Heavy duty swivel casters
- Rain hat (covers jack upper head)
- Hard chrome plated cylinder bore
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 3 year standard warranty
- Shipment on domestic skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Customer specified paint color
- Export crating
Aircraft Applications: -
Standard Features
- Patented floating cylinder assembly allows unit to track arc of landing gear jack point, eliminating excessive side loads on jack and landing gear thus providing safer operation and extending jack life
- Double acting auto-retract cylinder assembly incorporates a fluid bath for sealing surfaces to minimize corrosion and extend seal life. It also includes Skydrol resistant seals and bronze upper bearings for longer service life.
- Auto-retract plungers remain fully retracted while jack is being towed or in storage to protect against corrosion, contaminants and accidental damage
- Single valve control for simple and easy aircraft raising, lowering and auto-retract. Jack retracts to full retracted position automatically which provides for easy removal from under aircraft jack point after each operation
- Control console with all controls conveniently mounted for ease of operation.
- Hydraulic fuse at the cylinder assembly prevents lowering of load in the event of a hose failure
- 8 inch diameter heavy duty swivel casters and retractable front wheel with Skydrol resistant tread. The tow handle actuated front wheel provides improved ground clearance for towing.
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Oil filter cap with filtered air vent and dipstick
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container with skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Air line lubricator (for air operated hydraulic pump)
- Rain hat (covers cylinder assembly)
- Customer specified paint color
Aircraft Applications: -
-
Standard Features
- Manual hand pump with high, medium and low pressure operating positions
- Heavy duty tow handle and swivel casters with swivel locks for improved towing
- Rain hat (covers jack upper head)
- Hard chrome plated cylinder bore
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 3 year standard warranty
- Shipment on domestic skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Adjustable swivel feet with level for leveling jack
- Hydraulic operated casters provide ease in jack leveling and increased ground clearance for towing
- Platform mounted operating controls allow one person to position locknut while controlling lifting and lowering operations
- Ladder/platform
- Customer specified paint color
- Export crating
Aircraft Applications: -
Looking For Custom Parts?
Contact Us -
-
Standard Features
- Hard chrome plated cylinder and plunger bores
- Extension screw and hand pump parts are plated to resist corrosion
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Air operated hydraulic pump for power operation
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container
Optional Features
- Customer specified paint color
Aircraft Applications: -
Standard Features
- Axle Jack Cart
- Oil Pressure at 95 Ton Axle Jack Rated Capacity ........................ 6440 psig (453 kg/sq cm)
- Safety Pop-off Valve (field adjustable) factory set at ..................... 100 tons (91 m. tons)
- Reservoir Capacity ............................................................................. 5.5 gal (20.8 liters)
- Hydraulic Fluid ..................................................................................... Conoco Super Hydraulic 32 or equal
- Hydraulic Hose (2 each) .................................................................... 20 ft (6100 mm)
- Pneumatic Hose (1 each) .................................................................. 50 ft (15,240 mm)
- Cart Dimensions and Weight:
- Length ................................................................................................... 90 in (2,286 mm)
- Width ..................................................................................................... 40 in (1,016 mm)
- Height (towbar stowed) ...................................................................... 58 in (1,473 mm)
- Weight ................................................................................................... 2700 lbs (1220 kg)
- 1.4.2 95 Ton Axle Jacks (2 Each)
- Rated Capacity .................................................................................... 95 tons (86 m. tons)
- Low Height ........................................................................................... 10 in (254 mm)
- Hydraulic Lift......................................................................................... 10 in (254 mm)
- Extension Screw ................................................................................. 4 in (102 mm)
- Total Extended Height ........................................................................ 24.00 in (610 mm)
- Proof Load ............................................................................................ 142.5 tons (129.5 m. tons)
- Floor Loading at Rated Capacity ...................................................... 950 psi (66.8 kg/sq cm)
- Approximate Axle Jack Net Weight (dry) ........................................ 265 lbs (120 kg)
- A field adjustable safety pop-off valve is incorporated in the axle jack cart (located at the lower right behind the control panel) to prevent axle jack lifting loads in excess of 100 tons (91 m. tons).
- A relief valve with manual try lever is incorporated in the air inlet to prevent over pressurization of the pneumatic system.
- The extension screw has a positive stop to prevent it from being extended beyond its safe thread engagement.
- A load gauge for monitoring the approximate load being raised.
- The 95 ton axle jacks have safety locknuts (with a retainer to prevent removal from jack) to prevent lowering under load.
Aircraft Applications: -
Standard Features
- Manual hand pump with high, medium and low pressure operating positions
- Heavy duty tow handle and swivel casters with swivel locks for improved towing
- Hydraulic "thermal" relief valve for added protection and safety in the event of internal fluid expansion due to temperature
- Secondary cylinder seal for protection against contaminants and to prolong life of primary seal
- Rain hat (covers jack upper head)
- Hard chrome plated cylinder bore
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 3 year standard warranty
- Shipment on domestic skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Adjustable swivel feet with level for leveling jack
- Ladder/platform
- Platform mounted operating controls allow one person to position locknut while controlling lifting and lowering operations
- Customer specified paint color
- Export crating
Aircraft Applications: -
Standard Features
- Manual hand pump with high, medium and low pressure operating positions
- Heavy duty tow handle and swivel casters with swivel locks for improved towing
- Hydraulic "thermal" relief valve for added protection and safety in the event of internal fluid expansion due to temperature
- Secondary cylinder seal for protection against contaminants and to prolong life of primary seal
- Rain hat (covers jack upper head)
- Hard chrome plated cylinder bore
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 3 year standard warranty
- Shipment on domestic skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Adjustable swivel feet with level for leveling jack
- Ladder/platform
- Platform mounted operating controls allow one person to position locknut while controlling lifting and lowering operations
- Customer specified paint color
- Export crating
Aircraft Applications: -
Looking for Additional Support?
Contact UsMaintenance Schedules for Aircraft Shoring & Lifting Equipment
Proper maintenance for aircraft lifting and shoring equipment is imperative for extending the life of your equipment. That’s why we offer maintenance schedules for every piece of equipment in our catalog. Our guides for preventative maintenance for aircraft lifting equipment have everything you need to keep your equipment in top shape for years to come. If you’re looking to service your aircraft shoring equipment, we’ve got you covered!
