Axle Jacks
Showing 13 - 24 of 111
-
-
Standard Features
- Two stage hand pump for rapid cylinder extension (low pressure/high volume and high pressure/low volume)
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (white)
- Factory proof load @150% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container
Optional Features
- Customer specified paint color
- Permanent shipping and storage ATA enclosure
Aircraft Applications: -
Standard Features
- Two stage hand pump for rapid cylinder extension (low pressure/high volume and high pressure/low volume)
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (white)
- Factory proof load @150% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container
Optional Features
- Customer specified paint color
- Permanent shipping and storage ATA enclosure
Aircraft Applications: -
-
-
-
Looking For Custom Parts?
Contact Us -
Standard Features
- Hard chrome plated cylinder and plunger bores
- Extension screw and hand pump parts are plated to resist corrosion
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Air operated hydraulic pump for power operation
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container
Optional Features
- Customer specified paint color
Aircraft Applications: -
Standard Features
- Patented floating cylinder assembly allows unit to track arc of landing gear jack point, eliminating excessive side loads on jack and landing gear thus providing safer operation and extending jack life
- Double acting auto-retract cylinder assembly incorporates a fluid bath for sealing surfaces to minimize corrosion and extend seal life. It also includes Skydrol resistant seals and bronze upper bearings for longer service life.
- Auto-retract plungers remain fully retracted while jack is being towed or in storage to protect against corrosion, contaminants and accidental damage
- Single valve control for simple and easy aircraft raising, lowering and auto-retract. Jack retracts to full retracted position automatically, which provides for easy removal from under aircraft jack point after each operation.
- Control console with all controls conveniently mounted for ease of operation
- Hydraulic fuse at the cylinder assembly prevents lowering of load in the event of a hose failure
- 8 inch diameter heavy duty swivel casters and retractable front wheel with Skydrol resistant tread. Shock absorbing spring loaded front caster retracts automatically while jacking.
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Oil filter cap with filtered air vent and dipstick
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 150% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container with skid
Optional Features
- Air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Air line lubricator (for air operated hydraulic pump)
- Rain hat (covers cylinder assembly)
- Customer specified paint color
Aircraft Applications: -
Standard Features
- Patented floating cylinder assembly allows unit to track arc of landing gear jack point, eliminating excessive side loads on jack and landing gear thus providing safer operation and extending jack life
- Double acting auto-retract cylinder assembly incorporates a fluid bath for sealing surfaces to minimize corrosion and extend seal life. It also includes Skydrol resistant seals and bronze upper bearings for longer service life.
- Auto-retract plungers remain fully retracted while jack is being towed or in storage to protect against corrosion, contaminants and accidental damage
- Single valve control for simple and easy aircraft raising, lowering and auto-retract. Jack retracts to full retracted position automatically, which provides for easy removal from under aircraft jack point after each operation.
- Control console with all controls conveniently mounted for ease of operation
- Hydraulic fuse at the cylinder assembly prevents lowering of load in the event of a hose failure
- 8 inch diameter heavy duty swivel casters and retractable front wheel with Skydrol resistant tread. Shock absorbing spring loaded front caster retracts automatically while jacking.
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Oil filter cap with filtered air vent and dipstick
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 125% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container with skid
Optional Features
- Standard air operated hydraulic pump
- High speed air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Air line lubricator (for air operated hydraulic pump)
- Rain hat (covers cylinder assembly)
- Customer specified paint color
Variants
- 889900-16 - HIGH FLOW AIR PUMP, LUBRICATOR (REQUIRES HIGH FLOW AIR PUMP), RAIN HAT
- Currently Viewing 889900-17 - HIGH FLOW AIR PUMP, GAUGE, LUBRICATOR (REQUIRES HIGH FLOW AIR PUMP), RAIN HAT
Aircraft Applications: -
Standard Features
- Patented floating cylinder assembly allows unit to track arc of landing gear jack point, eliminating excessive side loads on jack and landing gear thus providing safer operation and extending jack life
- Double acting auto-retract cylinder assembly incorporates a fluid bath for sealing surfaces to minimize corrosion and extend seal life. It also includes Skydrol resistant seals and bronze upper bearings for longer service life.
- Auto-retract plungers remain fully retracted while jack is being towed or in storage to protect against corrosion, contaminants and accidental damage
- Single valve control for simple and easy aircraft raising, lowering and auto-retract. Jack retracts to full retracted position automatically, which provides for easy removal from under aircraft jack point after each operation.
- Control console with all controls conveniently mounted for ease of operation
- Hydraulic fuse at the cylinder assembly prevents lowering of load in the event of a hose failure
- 8 inch diameter heavy duty swivel casters and retractable front wheel with Skydrol resistant tread. Shock absorbing spring loaded front caster retracts automatically while jacking.
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Oil filter cap with filtered air vent and dipstick
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 125% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container with skid
Optional Features
- Standard air operated hydraulic pump
- High speed air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Air line lubricator (for air operated hydraulic pump)
- Rain hat (covers cylinder assembly)
- Customer specified paint color
Variants
- Currently Viewing 889900-16 - HIGH FLOW AIR PUMP, LUBRICATOR (REQUIRES HIGH FLOW AIR PUMP), RAIN HAT
- 889900-17 - HIGH FLOW AIR PUMP, GAUGE, LUBRICATOR (REQUIRES HIGH FLOW AIR PUMP), RAIN HAT
Aircraft Applications: -
Standard Features
- Patented floating cylinder assembly allows unit to track arc of landing gear jack point, eliminating excessive side loads on jack and landing gear thus providing safer operation and extending jack life
- Double acting auto-retract cylinder assembly incorporates a fluid bath for sealing surfaces to minimize corrosion and extend seal life. It also includes Skydrol resistant seals and bronze upper bearings for longer service life.
- Auto-retract plungers remain fully retracted while jack is being towed or in storage to protect against corrosion, contaminants and accidental damage
- Single valve control for simple and easy aircraft raising, lowering and auto-retract. Jack retracts to full retracted position automatically which provides for easy removal from under aircraft jack point after each operation.
- Control console with all controls conveniently mounted for ease of operation
- Hydraulic fuse at the cylinder assembly prevents lowering of load in the event of a hose failure
- 8 inch diameter heavy duty swivel casters and retractable front wheel with Skydrol resistant tread. The tow handle actuated front wheel provides improved ground clearance for towing.
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Oil filter cap with filtered air vent and dipstick
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 125% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container with skid
Optional Features
- Standard air operated hydraulic pump
- High speed air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Air line lubricator (for air operated hydraulic pump)
- Rain hat (covers cylinder assembly)
- Customer specified paint color
Variants
Aircraft Applications: -
Standard Features
- Patented floating cylinder assembly allows unit to track arc of landing gear jack point, eliminating excessive side loads on jack and landing gear thus providing safer operation and extending jack life
- Double acting auto-retract cylinder assembly incorporates a fluid bath for sealing surfaces to minimize corrosion and extend seal life. It also includes Skydrol resistant seals and bronze upper bearings for longer service life.
- Auto-retract plungers remain fully retracted while jack is being towed or in storage to protect against corrosion, contaminants and accidental damage
- Single valve control for simple and easy aircraft raising, lowering and auto-retract. Jack retracts to full retracted position automatically which provides for easy removal from under aircraft jack point after each operation.
- Control console with all controls conveniently mounted for ease of operation
- Hydraulic fuse at the cylinder assembly prevents lowering of load in the event of a hose failure
- 8 inch diameter heavy duty swivel casters and retractable front wheel with Skydrol resistant tread. The tow handle actuated front wheel provides improved ground clearance for towing.
- Two manual hand pumps (one high pressure, low volume and one low pressure, high volume)
- Oil filter cap with filtered air vent and dipstick
- Hard chrome plated cylinder and plunger bores
- All unpainted parts are plated to resist corrosion
- Skydrol resistant paint (safety yellow)
- Factory proof load @ 125% of rated capacity
- 1 year standard warranty
- Fully enclosed shipping container with skid
Optional Features
- Standard air operated hydraulic pump
- High speed air operated hydraulic pump
- Load gauge for load indication (reads tons/psig)
- Air line lubricator (for air operated hydraulic pump)
- Rain hat (covers cylinder assembly)
- Customer specified paint color
Variants
- Currently Viewing 885500-17 - HIGH FLOW AIR PUMP, GAUGE, LUBRICATOR (REQUIRES HIGH FLOW AIR PUMP), RAIN HAT
Aircraft Applications:
Find Aircraft Axle Jacks for Routine Maintenance Procedures at Tronair
Aircraft axle jacks are essential tools designed to lift an aircraft's landing gear off the ground, enabling mechanics to perform crucial tasks such as tire changes, brake maintenance, and inspections. The precision and strength required to lift an aircraft safely demand high-quality axle jacks that can handle substantial weight and provide stability. That's where Tronair comes in.
Tronair is proud to be the largest aircraft jack manufacturer in the industry. Our extensive selection of aircraft axle jacks caters to various aircraft models and maintenance needs. Like our tripod jacks, each Tronair axle jack is designed and manufactured with the utmost attention to detail, ensuring a durable, reliable lifting solution. We understand these tools' critical role in aviation safety, and our products are designed to exceed industry standards.
Tronair's Selection of Aircraft Axle Jacks
Tronair offers various aircraft axle jacks to meet various maintenance needs. Our hand-pump mechanical axle jacks are designed for ease of use and reliability, providing essential support for aircraft maintenance operations. These jacks are engineered to handle weight capacities ranging from 2 to 165 tons, ensuring that we have the right tool for any job, whether for business jets, military aircraft or commercial planes
Our axle jacks come in various models, each tailored to specific requirements:
-
Low-Profile Models: Ideal for aircraft with lower ground clearance, these jacks provide the necessary lift without compromising stability.
- High-Capacity Models: These jacks can lift heavier aircraft and are designed for robustness and durability, ensuring they can handle the increased weight.
- Adjustable Models: Some of our jacks include spacer blocks that allow for easy adjustment of the closed height, providing flexibility and convenience during maintenance tasks.
- Auto-Retract Models: Offer quicker lowering of the jack cylinder to allow for faster removal of the jack from under the aircraft.
- Air Driven Models: Include an air driven pump to increase the speed of raising the jack and increase efficiency.
For those looking for FAA-approved aircraft axle jacks, you can easily identify them by looking for a "C" as the eighth digit in the model number (e.g. 02-7813C0100). This designation ensures that the jack meets stringent industry standards for safety and performance.
Each Tronair axle jack is built with high-quality materials and precise engineering, making them indispensable tools for maintenance crews. Whether you are performing routine inspections or more extensive repairs, our axle jacks provide the support and reliability you need to get the job done efficiently and safely.
Tronair Axle Jack Pre-Use Inspection
Frequently Asked Questions: Axle Jacks for Aircraft
If you'd like to learn more about our selection of axle jacks for your aircraft, check out the answers to a few of our most commonly asked questions below.
